Hook / Primary Shredder for Solid Wastes

Hook / Primary shredder for coarse / primary shredding of household, bulky wastes and for combustible solid industrial waste

Inquire Now Next Product

Product Description

A series of hook / primary shredder had been extensively used in the Waste-To-Energy (WTE) plants, for size reduction of municipal wastes before incineration, in recycling plants for sorting of metals, inorganic solids, combustibles, and etc.

Hydraulic driven hook / primary shredder feature in low speed and high torque, and have advantages in high throughout and excellent suitability for various wastes.

Main Technical Parameters

	Overall Dim. (LxWxH,m)	Size of Shredding Chamber (LxW,m)	Capacity (t/h)	Size of Products (mm)	Installed Power (kW)	Weight (kg)
HS2-7500HB	5.3x3x1.6	2.9x2.6	30-150	250-450	400/500/630	30000
HS2-5000HB	4.8x2.5x1.2	2.6x1.8	50-100	200-300	280/315	21000
HS3-4000HT	4.6x3.1x1.5	2.0x2.0	15-50	200-300	280/315	16000
HS2-3200HB	3.6x2.1x0.95	2.0x1.6	30-50	150-250	160/200	11000

Note: The above data are standard configurations for typical models and can’t be taken as the only principle for type/model selection, and such facts as kind of wastes and their states, type of package, expected size after shredding etc. should also be taken into consideration, actual data are subject to adjustment according to specific requirements. More models and configurations are for inquiry and for face-to-face discussion.
